Reinforced Ceramic Fiber Cloth
Product Description:
Temp Grade: 1000°C,1260°C
Density: 500kg/m₃, 550kg/m₃
Specification:
• 2 x1000 x 30000mm
• 3×1000 x 30000mm
• 4×1000 x 30000mm
• 5×1000 x 20000mm
Customized specification is acceptable.
Share
Reinforced Ceramic Fiber Cloth
Reinforced Ceramic Fiber Cloth is a woven high-temperature insulation textile designed for industrial heat protection, thermal insulation, and sealing applications. Made from ceramic fiber yarn, it can be reinforced with glass fiber filament or metal wire, depending on the product specification, to improve handling strength and durability.
Mindelun supplies reinforced ceramic fiber cloth for industrial furnace maintenance, hot pipe wrapping, heat shields, furnace curtains, and high-temperature sealing applications. Custom widths, thicknesses, roll lengths, and reinforcement options are available upon request.
Key Features of Reinforced Ceramic Fiber Cloth
- High-temperature insulation: Helps protect equipment and personnel from radiant heat.
- Flexible woven structure: Suitable for wrapping, covering, and fabricating insulation components.
- Reinforcement options: Glass fiber or metal wire reinforcement, subject to product availability.
- Versatile fabrication: Can be cut and processed for thermal barriers, protective covers, and sealing components.
- Custom supply: Available in different dimensions and configurations according to project requirements.
Applications
Reinforced ceramic fiber cloth is commonly considered for:
- Industrial furnace curtains and heat shields
- High-temperature pipe and exhaust wrapping
- Thermal insulation covers and removable insulation jackets
- Expansion joint and equipment sealing applications
- Heat protection barriers in industrial maintenance
The suitable product grade depends on the operating temperature, exposure conditions, and required mechanical performance.
Product Specifications
| Item | Unit | Test Result | Test Result |
| Color | / | White | White |
| Specification temp | (℃) | 1260(Stainless steel fiber) | 1000(Glass fiber) |
| Using Temp | (℃) | 1000 | 650 |
| Fiber diameter | (um) | 44200 | 44200 |
| Shot content | (%) | ≤8.5 | ≤8.5 |
| Thermal conductivity of average temperature | （W/m.k) | 0.13-0.19(538℃,8pcf） | 0.13-0.19(538℃,8pcf） |
| (%) | 0.075-0.085(1232℃*24h） | 0.075-0.085(1232℃*24h） | |
| Al2O₃ | (%) | ≧45-46 | ≧45-46 |
| SiO₂ | (%) | 51-52 | 51-52 |
| Fe₂O₃ | (%) | ＜0.43 | ＜0.43 |
| Na₂O+K₂O | (%) | 0.7-1.2 | 0.7-1.2 |
| Thickness | (mm) | 2/3/4/5 | |
| Width | (mm) | 1000 | |
| Length | (mm) | 20000/30000 | |
Please confirm the actual product specifications, reinforcement type, and continuous service temperature before placing an order.
Why Choose Mindelun?
Mindelun supplies industrial thermal insulation materials for distributors, contractors, equipment manufacturers, and industrial end users. Our product range includes ceramic fiber cloth, ceramic fiber blanket, ceramic fiber board, and other high-temperature insulation products.
We support specification-based product selection, customized dimensions, and bulk supply to help buyers source suitable insulation materials for industrial projects.
Frequently Asked Questions
1. What is reinforced ceramic fiber cloth used for?
It is used for heat protection, furnace curtains, pipe wrapping, insulation covers, and selected high-temperature sealing applications.
2. What reinforcement options are available?
Depending on the product grade, reinforcement may include glass fiber filament or metal wire. Please confirm the available construction before ordering.
3. Can reinforced ceramic fiber cloth be customized?
Yes. Width, thickness, roll length, and reinforcement options can be discussed according to the application and supply requirements.
4. How do I choose the correct temperature rating?
Consider the actual operating temperature, exposure duration, atmosphere, and reinforcement material. The maximum classification temperature should not be treated as the continuous service temperature.
5. Can Mindelun supply other ceramic fiber insulation products?
Yes. You can also explore our Ceramic Fiber Blanket and Industrial Furnace Insulation solutions.
Request a Quote
Looking for a reinforced ceramic fiber cloth supplier for your industrial insulation project? Contact Mindelun with your required dimensions, reinforcement type, operating temperature, and estimated quantity. Our team can help you confirm a suitable product specification.
