High Temperature Ceramic Fiber Paper for Industrial Insulation
Temp Grade: 1050°C,1260°C,1400°C, 1430°C
Density: 180kg/m₃, 200kg/m₃
Specification:
• 0.5 x610/1200 x 120000mm
• 1 x610/1200 x 60000mm
• 2 x610/1200 x 30000mm
• 3 x610/1200 x 20000mm
• 4×610/1200 x 15000mm
• 5×610/1200 x 12000mm
• 6×610/1200 x 10000mm
• 10×610/1200 x 6000mm
Customized specification is acceptable.
Share
High Temperature Ceramic Fiber Paper for Industrial Insulation
Mindelun Ceramic Fiber Paper is a lightweight, flexible refractory insulation material manufactured from ceramic fibers through a specialized paper-making process. Designed for high-temperature thermal insulation, sealing, and heat protection, ceramic fiber insulation paper offers low thermal conductivity, uniform thickness, and convenient fabrication.
Available in roll and sheet formats, ceramic fiber paper is suitable for furnace insulation, high-temperature gaskets, thermal barriers, and other industrial applications. Different grades, thicknesses, and dimensions can be selected according to operating conditions and project requirements.
As an industrial insulation materials supplier, Mindelun supports distributors, wholesalers, contractors, and equipment manufacturers seeking ceramic fiber paper for industrial production, maintenance, and thermal processing.
Key Benefits of Ceramic Fiber Paper
High-Temperature Resistance
High temperature ceramic fiber paper is designed for suitable industrial thermal environments. Its temperature rating depends on fiber composition, product grade, and manufacturing specifications. Buyers should confirm both classification temperature and recommended continuous operating temperature before selecting a product.
Low Thermal Conductivity
Ceramic fiber insulation paper helps reduce heat transfer when incorporated into a properly designed insulation system. It can serve as a thin thermal barrier in furnaces, heating equipment, and other high-temperature applications.
Lightweight and Flexible
The flexible structure of ceramic fiber paper makes it convenient to handle, cut, wrap, and fit around suitable components. Compared with rigid refractory insulation products, it is particularly useful where thin insulation layers or flexible material formats are required.
Uniform Thickness and Easy Fabrication
Ceramic fiber paper is designed for consistent thickness and convenient processing. Depending on the grade, it can be cut or die-cut into gaskets, washers, seals, and custom-shaped insulation components.
Multiple Grade Options
Depending on product availability, buyers may select standard, high-purity, zirconia-containing, or binderless ceramic fiber paper. Each grade should be evaluated according to its technical specifications and intended operating conditions.
Types of Ceramic Fiber Paper
Standard Ceramic Fiber Paper
Standard ceramic fiber paper is suitable for general-purpose thermal insulation, furnace lining layers, heat shields, and gasket fabrication. It is commonly selected for industrial applications that require flexible, thin refractory insulation.
High-Purity Ceramic Fiber Paper
High-purity ceramic fiber paper is intended for applications with specific requirements for chemical composition and impurity control. Confirm the relevant material specifications before ordering.
Zirconia Ceramic Fiber Paper
Zirconia-containing ceramic fiber paper is designed for selected higher-temperature applications. Its suitability depends on the specific grade, temperature rating, and service conditions.
Binderless Ceramic Fiber Paper
Binderless ceramic fiber paper is manufactured without an organic binder system. It may be suitable for applications where binder-related smoke or organic outgassing must be minimized. Confirm availability and technical properties for the selected product.
Industrial Applications of Ceramic Fiber Paper
Furnace and Kiln Insulation
Ceramic fiber paper can be used as a thin insulation layer, backup insulation, or parting layer in suitable industrial furnaces, ceramic kilns, and thermal processing equipment.
For applications requiring thicker or more rigid insulation, buyers can also explore our ceramic fiber board for suitable furnace lining and thermal insulation requirements.
High-Temperature Gaskets and Seals
Ceramic fiber paper can be converted into gaskets, washers, and sealing components for suitable high-temperature equipment. The material grade and thickness should match the required temperature, compression, and sealing conditions.
Thermal Barriers and Heat Shields
As a thin thermal barrier, ceramic fiber insulation paper helps protect selected components from heat exposure. It may be used in industrial heating equipment and other applications requiring lightweight refractory insulation.
Pipe and Equipment Insulation
Flexible ceramic fiber paper can be used on suitable components requiring thin thermal insulation. For applications requiring thicker, conformable insulation, consider our ceramic fiber blanket, subject to the project’s temperature and installation requirements.
Ceramic, Glass, and Metal Processing
Ceramic fiber paper may serve as a separator, protective layer, or refractory insulation component in selected ceramic, glass, and metal processing applications.
For other flexible refractory textile requirements, explore our ceramic fiber tape and ceramic fiber cloth.
Ceramic Fiber Paper Specifications
Ceramic fiber paper is available in different grades and dimensions. The following specifications should be confirmed according to the selected product and current manufacturing availability.
| Item | Unit | Test Result | Test Result | Test Result | Test Result | |
| 2 | Specification temp | (℃) | 1260(ST) | 1260(HP) | 1360(HA) | 1430(HZ) |
| 3 | Working temperature | (℃) | 1050 | 1100 | 1200 | 1350 |
| 4 | Density | (kg/m3) | 180/200 | 180/200 | 180/200 | 180/200 |
| 5 | Permanent shrinkage Rate of liner (24h, density 200kg/m3) | (%) | -3 | -3 | -3 | -3 |
| (1000℃） | (1100℃） | (1200℃） | (1350℃） | |||
| 6 | Thermal conductivity of each heat surface(density 200kg/m3) | （W/m.k) | 0.1(400℃） | 0.1(400℃） | 0.1(400℃） | 0.1(400℃） |
| 0.12（800℃） | 0.12（800℃） | 0.13（800℃） | 0.19（800℃） | |||
| 7 | Moisture content | (%) | ≤1% | ≤1% | ≤1% | ≤1% |
| 8 | Compression strength (density 200kg/m3) | (Mpa) | ≧0.3 | ≧0.3 | ≧0.3 | ≧0.3 |
| 9 | Shot contenT | (%) | ≤10% | ≤10% | ≤10% | ≤10% |
| 10 | Al2O3 | (%) | ≧43 | ≧45 | ≧52 | ≧35 |
| 11 | Al2O3+SiO2 | (%) | 97 | 97 | 97 | 97 |
| 12 | Fe2O3 | (%) | ＜1.0 | ＜1.0 | ＜1.0 | ＜1.0 |
| 13 | Na2O+K2O | (%) | ＜0.5 | ＜0.5 | ＜0.5 | ＜0.5 |
| 14 | Aluminum foil thickness | (mm) | 0.05-0.1 | |||
| 15 | Aluminum foil radiation heat rate | (%) | ≧80 | |||
| 16 | Thickness | (mm) | 0.5/1/2/3/4/5/6/10 | |||
| 17 | Width | (mm) | 500/610/1000/1200/1220 | |||
| 18 | Length | (mm) | 10000/12000/15000/20000/30000/60000/120000 | |||
Note: The listed thicknesses are indicative options, not a guarantee that every size is available. Confirm the exact specifications, temperature rating, and customization options with Mindelun before ordering. Classification temperature is not equivalent to continuous operating temperature.
Why Choose Mindelun for Ceramic Fiber Paper?
Mindelun supplies industrial thermal insulation materials for distributors, wholesalers, contractors, and equipment manufacturers. Our product portfolio covers different ceramic fiber insulation requirements for industrial thermal management and refractory applications.
- B2B Supply Support: Supply solutions for industrial buyers, distributors, wholesalers, and project procurement.
- Specification-Based Selection: Product recommendations based on operating temperature, dimensions, and application requirements.
- Related Product Sourcing: Source ceramic fiber paper alongside ceramic fiber board, blanket, tape, cloth, and other industrial insulation products.
- Custom Requirements: Discuss dimensions, cutting formats, packaging, and order quantities with our sales team.
Contact Mindelun with your application details and purchasing requirements to discuss suitable ceramic fiber paper and related insulation materials.
Frequently Asked Questions
What is ceramic fiber paper used for?
Ceramic fiber paper is used for high-temperature insulation, furnace and kiln lining layers, thermal barriers, gaskets, seals, and other suitable refractory applications.
What temperature can ceramic fiber paper withstand?
The temperature limit depends on the fiber composition and product grade. Classification temperature and continuous operating temperature are different, so buyers should confirm the technical data for the specific product before use.
What thicknesses are available for ceramic fiber paper?
Available thicknesses depend on the grade and manufacturing capabilities. Common options may include 1–6 mm. Confirm the required thickness, width, and roll length when requesting a quotation.
Can ceramic fiber paper be cut into custom gaskets?
Yes. Ceramic fiber paper can generally be die-cut into suitable gaskets, washers, and sealing shapes. Final suitability depends on the material grade, thickness, compression requirements, and service environment.
What is the difference between standard and binderless ceramic fiber paper?
Standard ceramic fiber paper may contain an organic binder that burns out during initial heating. Binderless paper is manufactured without an organic binder system and may be preferred when minimizing binder-related smoke or outgassing is important.
How can I request a quotation for ceramic fiber paper?
Provide the required grade, thickness, width, roll length, operating temperature, application, estimated quantity, and delivery destination. This information helps Mindelun assess your requirements and prepare a suitable quotation.
Contact Mindelun for Ceramic Fiber Insulation Solutions
Looking for a ceramic fiber paper manufacturer or supplier for your industrial project or distribution business? Contact Mindelun with your technical specifications and purchasing requirements to discuss suitable high-temperature insulation materials.
