Ceramic Fiber Tape Supplier for High-Temperature Insulation and Sealing
Product Description:
Temp Grade: 1000°C,1260°C
Density: 500kg/m₃, 550kg/m₃
Specification:
• 2 x25/50/75/100 x 30000mm
• 3×25/50/75/100 x 30000mm
• 4×25/50/75/100 x 30000mm
• 5×25/50/75/100 x 20000mm
Customized specification is acceptable.
Share
Ceramic Fiber Tape Manufacturer & Supplier for High-Temperature Insulation
Mindelun supplies ceramic fiber tape for industrial thermal insulation, heat shielding, and high-temperature sealing applications. Made from woven aluminosilicate ceramic fiber yarn, this flexible high-temperature insulation tape offers low thermal conductivity, low heat storage, and good thermal shock resistance. It is suitable for pipe wrapping, furnace door sealing, exhaust systems, and selected gasket and expansion joint applications.
As a ceramic fiber tape supplier, Mindelun supports customized widths, thicknesses, roll lengths, and reinforcement options for distributors, industrial contractors, and equipment manufacturers seeking reliable ceramic fiber insulation materials for bulk purchasing.
Key Features of Ceramic Fiber Tape
- High-Temperature Insulation: Helps reduce heat transfer in suitable industrial operating conditions.
- Flexible Woven Structure: Suitable for wrapping pipes, ducts, and irregular equipment surfaces.
- Reinforced Options: Available with suitable glass fiber or metal wire reinforcement, depending on the product grade.
- Multiple Tape Designs: Standard woven, reinforced ceramic fiber tape, and Drop Warp constructions.
- Custom Manufacturing: Specifications can be discussed according to project requirements and order quantities.
Ceramic Fiber Tape Specifications
| Item | Unit | Test Result | Test Result |
| Color | / | White | White |
| Specification temp | (℃) | 1260(Stainless steel fiber) | 1000(Glass fiber) |
| Using Temp | (℃) | 1000 | 650 |
| Fiber diameter | (um) | 44200 | 44200 |
| Shot content | (%) | ≤8.5 | ≤8.5 |
| Thermal conductivity of average temperature | （W/m.k) | 0.13-0.19(538℃,8pcf） | 0.13-0.19(538℃,8pcf） |
| (%) | 0.075-0.085(1232℃*24h） | 0.075-0.085(1232℃*24h） | |
| Al2O₃ | (%) | ≧45-46 | ≧45-46 |
| SiO₂ | (%) | 51-52 | 51-52 |
| Fe₂O₃ | (%) | ＜0.43 | ＜0.43 |
| Na₂O+K₂O | (%) | 0.7-1.2 | 0.7-1.2 |
| Thickness | (mm) | 2/3/4/5 | |
| Width | (mm) | 25/50/75/100 | |
| Length | (mm) | 20000/30000 | |
Contact Mindelun for available sizes, technical data sheets, and product-specific temperature limits.
Applications of High-Temperature Ceramic Fiber Tape
Pipe Insulation: Ceramic fiber tape can be used for thermal wrapping of suitable hot pipes, ducts, and exhaust components. For other insulation requirements, explore our ceramic fiber blanket products.
Furnace Door Sealing: Flexible ceramic fiber tape can help insulate and seal suitable furnace openings and joints. Learn more about our industrial furnace insulation solutions.
Gaskets and Expansion Joints: Ceramic fiber gasket tape is suitable for selected high-temperature sealing applications where the material and construction meet operating requirements. Ceramic fiber rope may also be considered for suitable gap-filling applications.
Heat Shielding: Ceramic fiber tape can provide thermal protection for selected industrial components exposed to elevated temperatures.
Equipment Insulation: For rigid insulation requirements, Mindelun also supplies ceramic fiber board for compatible furnace linings and industrial equipment.
Ceramic Fiber Tape Types
- Standard Woven Ceramic Fiber Tape: Flexible tape for general thermal insulation and wrapping.
- Reinforced Ceramic Fiber Tape: Incorporates suitable glass fiber or metal wire reinforcement to improve handling strength and dimensional stability.
- Drop Warp Ceramic Fiber Tape: Features a special woven construction for selected bolted sealing and gasket applications.
The right ceramic fiber tape depends on working temperature, reinforcement compatibility, installation method, and mechanical requirements.
Ceramic Fiber Tape Wholesale and Custom Supply
Mindelun supports bulk purchasing and customized specifications for industrial distributors, contractors, and equipment manufacturers. As a ceramic fiber insulation supplier, we help customers select suitable products according to their operating conditions and project requirements.
Request a Quote: Send us your required width, thickness, roll length, operating temperature, reinforcement preference, and order quantity to request product details and a quotation.
Frequently Asked Questions
What is ceramic fiber tape used for?
Ceramic fiber tape is used for high-temperature insulation, pipe wrapping, furnace door sealing, heat shielding, and selected gasket applications.
What is the operating temperature of ceramic fiber tape?
The operating temperature depends on the ceramic fiber grade, reinforcement material, and service conditions. Confirm the continuous operating temperature and short-term exposure requirements before ordering.
Is reinforced ceramic fiber tape available?
Yes. Depending on the product grade, glass fiber or metal wire reinforcement may be available to meet different mechanical and temperature requirements.
Can I order custom ceramic fiber tape?
Yes. Width, thickness, roll length, and reinforcement options can be discussed according to application requirements and order quantity.
How do I choose a ceramic fiber tape manufacturer?
Compare product specifications, reinforcement options, dimensional consistency, technical documentation, and the supplier’s ability to meet your application and bulk order requirements.
