Medium Density Calcium Silicate Board Manufacturer & OEM Supplier
Product Description:
Temp Grade: 650°C, 1000°C.
Density: 400kg/m₃–800kg/m₃
Specification:
• 1000 mm x 500mm x 20-120mm ( Thickness)
• 600mm x 300mm x 20-120mm ( Thickness )
• 1200mm x 1200mm x 20-120mm ( Thickness )
• 1200mm x 2440mm x 20-120mm ( Thickness )
Customized specification is acceptable.
Share
Medium Density Calcium Silicate Board Manufacturer & OEM Supplier
MINDELUN supplies medium density calcium silicate board for industrial thermal insulation, equipment insulation, and customized insulation components. With five nominal density options ranging from 400 to 800 kg/m³, our calcium silicate insulation boards offer different combinations of mechanical strength and thermal performance for industrial applications.
Designed for applications requiring rigid insulation materials, MINDELUN calcium silicate boards are available in thicknesses from 20 to 120 mm, with standard and customized dimensions subject to production requirements. We also support CNC machining, special-shaped fabrication, and OEM packaging for eligible orders.
As a calcium silicate board OEM supplier, we work with insulation distributors, industrial equipment manufacturers, engineering contractors, and other B2B buyers seeking customized insulation products and reliable technical support.
Key Features of Calcium Silicate Insulation Board
1. Five Density Grades for Different Requirements
MINDELUN calcium silicate board is available in nominal densities of 400, 500, 650, 750, and 800 kg/m³. This range allows buyers to compare mechanical strength, weight, and insulation properties when selecting a suitable grade.
Higher-density grades generally offer greater mechanical strength within this product range, while the appropriate choice depends on the actual installation and performance requirements.
2. Thermal Insulation for Industrial Applications
Calcium silicate insulation board helps reduce heat transfer in properly designed thermal insulation systems. The supplied product specifications state a maximum service temperature of 1000°C.
Actual suitability depends on the selected density grade, operating temperature, exposure duration, and installation conditions. Buyers should consult the applicable technical data before using the board in high-temperature equipment.
3. Mechanical Strength and Rigid Structure
Depending on the selected grade, the specified minimum bending strength ranges from 1.5 to 8 MPa, while minimum compressive strength ranges from 3 to 17 MPa.
These properties help buyers evaluate the board for applications where handling, installation, and mechanical support are important.
4. CNC Machining and Custom Fabrication
In addition to standard boards, MINDELUN supports CNC machining and customized cutting according to approved drawings and manufacturing feasibility.
Available customization options can be discussed for:
- Non-standard board dimensions and thicknesses.
- Precision-cut insulation components.
- Special-shaped boards and machined parts.
- OEM packaging and private-label requirements.
Calcium Silicate Board Technical Specifications
| Physical properity | Unit | MINDELUN BRAND–1000℃ | ||||
| Bulk density | kg/m₃ | 400±10% | 500±10% | 650±10% | 750±10% | 800±10% |
| Bending strength | MPa | ≥1.5 | ≥2.2 | ≥3.0 | ≥6.0 | ≥8 |
| Compress Strength | MPa | ≥3.0 | ≥4.0 | ≥5.0 | ≥10 | ≥17 |
| Thermal conductivity at 900℃ | W/m.k | ≤0.11 | ≤0.14 | ≤0.15 | ≤0.16 | ≤0.12 |
| Max using temp | ℃ | 1000 | 1000 | 1000 | 1000 | 1000 |
| Shrinkage Rate of liner | % | ≤1.2(1000,3hrs) | ≤3.0(1000,3hrs) | ≤1.2(850,24hrs) | ≤1.61(850,24hrs) | ≤1.61(850,24hrs) |
| Length*Width | 1000*500
600*300 1200*1200 1220*2440 |
|||||
| Thickness | 20-120mm | |||||
| SiO₂ | 46-48% | |||||
| CaO | 39—41% | |||||
| AlO₃ | 0.39-0.42% | |||||
| MgO | 0.5-0.7% | |||||
| Fe2O₃ | 0.3-0.4% | |||||
| Na2-K2O | 0.9—0.12% | |||||
| LOI | 8—11% | |||||
Thermal conductivity, linear shrinkage, and chemical composition vary by density grade. Please request the relevant technical data sheet for complete grade-specific information.
Applications of Medium Density Calcium Silicate Board
MINDELUN calcium silicate insulation board can be evaluated for industrial applications where the product’s technical properties match the service conditions.
Industrial Equipment Insulation
For selected industrial equipment and thermal processing systems requiring rigid insulation materials.
Furnace and Kiln Insulation
For suitable insulation layers and backing components in furnace and kiln assemblies, subject to the specified temperature rating and installation design.
Thermal Processing Equipment
For selected industrial production equipment requiring thermal insulation and dimensionally stable board components.
Customized Insulation Components
For OEM projects that require CNC-machined boards, special cutouts, or components manufactured to customer drawings.
Industrial Maintenance and Replacement
For replacement insulation components where dimensions, density, mechanical properties, and operating conditions must match project requirements.
For direct flame exposure or demanding high-temperature service, verify the material’s suitability before installation.
Your Calcium Silicate Board OEM Supplier
Choosing the right calcium silicate board OEM supplier means finding a partner that understands product specifications, customization requirements, and commercial procurement needs.
MINDELUN supports B2B customers with:
- Customized dimensions: Board sizes and thicknesses subject to production feasibility.
- CNC machining: Precision cutting and special-shaped processing according to approved drawings.
- OEM packaging: Packaging and private-label options for eligible products.
- Multiple density grades: Five nominal density options to support different project requirements.
- Quotation support: Pricing based on material grade, dimensions, processing requirements, order quantity, and destination.
Our team can review your technical specifications and drawings to help identify suitable products for your industrial insulation project.
Explore our related Ceramic Fiber Board and Industrial Furnace Insulation solutions.
Frequently Asked Questions
What density options are available for MINDELUN calcium silicate board?
The specified range includes 400, 500, 650, 750, and 800 kg/m³ nominal density grades. Actual density tolerances should be confirmed against the applicable product specification.
What thicknesses and dimensions can you supply?
The supplied thickness range is 20–120 mm. Standard dimensions include 1000 × 500 mm, 600 × 300 mm, 1200 × 1200 mm, and 1220 × 2440 mm. Other dimensions can be discussed according to manufacturing feasibility.
Can calcium silicate boards be CNC machined?
Yes. CNC machining and customized cutting are supported. Buyers should provide drawings, dimensions, tolerances, and quantity requirements for evaluation.
Does MINDELUN offer OEM calcium silicate board services?
Yes. OEM packaging, private labeling, and eligible customized specifications can be discussed according to the product and order requirements.
Is MINDELUN calcium silicate board asbestos-free?
The product is specified as asbestos-free. Buyers who require formal documentation should request the applicable manufacturer declaration or test report.
What is the maximum service temperature?
The supplied specifications state a maximum service temperature of 1000°C. The appropriate grade must be selected according to the actual temperature profile, exposure duration, and installation conditions.
Request a Quote for Calcium Silicate Insulation Board
Looking for a calcium silicate board OEM supplier for your industrial insulation project?
Contact MINDELUN with your required density, thickness, board dimensions, operating temperature, quantity, and machining or OEM requirements.
Our team can review your specifications and provide a quotation based on available product grades and manufacturing capabilities.
Contact MINDELUN for medium density calcium silicate board, CNC machining, customized dimensions, and OEM supply solutions.
